模塊混凝士攪拌站系列

MODULAR CONCRETE MIXING PIANT SERIES

項目Item/型號Model		HZS25	HZS35	HZS50	HZS75	HZS100
項目Item/型號Model		HZS25	HZS35	HZS50	HZS75	HZS100
整機 Whole machine	理論生產率(m³/h) Theoreical productivity	25	35	50	75	100
	控制方式 control mode	微機 Computer
	計量方式 Weighing mode	電子秤 Electrical scale
	出料高度 Discharging height	3.8
	整機裝機容量 Whole machinery capacity	55	85	110	150	180
攪拌機 Mixer	攪拌機型號 Model of mixer	JS500	JS750	JS1000	MT1500	MT2000
	攪拌機功率 mixing power	18.5	30	18.5x2	30x2	37x2
	入料容積（L） Charging volume	800	1250	1500	2250	3000
	出料容積（L) Discharging volume	500	750	1000	1500	2000
	料徑碎石／卵石 Diameter of macadarn/pebble	40-60	40-60	40-80	40-80	40-80
骨料儲供系統 Aggregate storage system	配料秤型號 Batcher scale model	PL800	PL1200	PL1600	DPL2400	DPL3200
	配科種類 Types of ingredients	2－3Piece(種)	3Piece(種)	3Piece(種)	3－4Piece(種)	4Piece(種)
	砂石儲料倉容積（m³） Aggregate storage hopper volume	3x2-3	3.4x3	5x3	8x3	15x3
	計量范圍及精度 Weighing range & accuracy	200-1500±2%	200-2000±2%	200-2500±2%	200-3500±2%	200-5000±2%
	理論生產能力(t/h) Theoretical capacity	80	100	140	190	260
粉料儲供系統 Powder storage	粉料存儲能力 Powder storage capacity	50x1	50x2	100x2	100x2	100x4
	螺旋輸送機能力(t/h) Screw conveyer capacity	30	35	45	55	80
	水泥計量范及精度 Cement weighing range&accuracy	50-300±1%	50-400±1%	100-600±1%	100-1000±1%	100-1100±1%
水外加劑緒供系統 Water addives storage system	水計量范圍 Water weighing range	50-150	50-200	50-350	50-450	50-500
	水計量精度 Water weighing accuracy	±1%
	液態外加劑量范國(kg) Liquid additives weighing range	5-20	5-20	5-20	5-30	5-60
	液態外加劑量精度 Liquid additives weighing accuracy	±1%
