升 降 機 系 列
CONSTRUCTION HOIST SERIES
SC100/100、SC200/200系列升降機主要技術參數
Main technical parameters of SC100/100 and SC200/200 series construction hoist
|
產品類別 Model |
SC100/100系列 Series | SC200/200 系列 Series | |||
| 產品型號 Model | SC100/100C | SC100/100PD | SC200/200 | SC200/200PD | SC200/200PZ |
| 額定載重量 Rated capacity(kg) |
2×1000 |
2×2000 |
|||
| 提升速度 Lifting speed（m/min） | 34 | 0-40 | 34 | 0-40 | 0-63 |
| 電機功率Motor power(kw) |
2×2×11 |
2×2×15，2×2×13，2×3×11 | 2×2×13 | 2×3×18.5 | |
| 變頻器功率Inverter power(kw) |
|
2×30 |
|
2×30 | 2×75 |
| 吊籠尺寸(m)(長×寬×高) Sizes of the inside cage(m)(L×W×H) | 3×1.3×2.15 |
3×1.3（1.5）×2.15 |
|||
| 標準節高度(m) Standard section height |
1.508 |
||||
